RR60MCS

The RR60 is an extra heavy-duty 12V 60 Amp 3 phase Regulator Rectifier. This rectifier has been tested in Taiwan and has been granted Patent No.M326747. Improved design, cooler operation and greater efficiency.

• Mounting Hole Distance  65-75mm

• Dimensions 80 x 85 x 30mm

• Designed to handle increased power loads
• Upgraded rectifier components
• Heavy-duty regulation circuit
• Provides a stable charge rate of the battery
• Advanced heatsink design


When Installing a new Regulator/Rectifier (R/R):

1. Select the correct type and output model of R/R
2. Check correct Battery is Fitted and performing at 100%
3. Check Charging system (incl. Coil) is operating at 100%
4. Check the stator coil for grounding and correct output
5. Tit to the bike in accordance to OEM specs and guidelines
6. Apply Heat Transfer Compound to the bae of the R/R when mounting to the frame
7. Check that cooling ventilation is adequate
