Dellorto Carburettor PHBL 22AS 4 stroke
$334.40 (inc GST) $304.00 (exc GST)
Dellorto Carburettor PHBL 22AS 4 stroke
$334.40 (inc GST) $304.00 (exc GST)
| This product is available for pre-order only |
![Pin It](http://pinterest.com/pin/create/button/?url=https://damclassicracing.com.au/dellorto-carburettor-phbl-22as-4-stroke/&media=https://cdn10.bigcommerce.com/s-roz2thw8d1/products/4067/images/6425/R2709_PHBL_22AS_4_stroke__01_wm__57801.1758694295.1280.1280.jpg?c=2&description=DAM Classic Racing - Dellorto Carburettor PHBL 22AS 4 stroke, <span class="ProductDetailsPriceIncTax">$334.40 (inc GST)</span> <span class="ProductDetailsPriceExTax">$304.00 (exc GST)</span> (https://damclassicracing.com.au/dellorto-carburettor-phbl-22as-4-stroke/))
Product Description
4 Stroke carburettor.
M38 x 1.25mm Threaded air intake.
Clamp type engine connection to suit 28.57 – 31.75mm stub diameter.
Lever type choke mechanism fitted, can be changed to cable operated mechanism if requested.
Standard jetting
- 40 Slide
- D24 Needle
- 268K Atomiser
- 100 Main jet
- 50 Idle jet
- 70 Choke jet
- 200 Needle valve
- 9010.1 Float – 9.5 grams
