This premium DAYCO Submersible Fuel Injection Hose supersedes Part Nr. LV002006000038 and LV002006000040 which suffered disintegration problems when submerged in the fuel tank.

8mm (5/16") Fuel Hose supplied in unit lengths of 500mm increments to suit Laverda 650, 668, 750 Zane models.

* Sold in 500mm increments up to maximum continuous length of 3 metres.

* A single 500mm length is required in most cases to allow access to service the Fuel Filter without removing the tank.

* Do Not use 300mm lengths, 300mm is too short for Laverda fuel tanks.

* Do Not use ordinary fuel injection fuel hose in a submersible situation.

In-Tank Fuel Line Hose is capable of handling gasoline, alcohol blended gasoline, E85 (ethanol fuel blend), diesel and bio diesel fuels used in mobile and stationary applications. It is designed for constant fuel contact in the inside and outside of the hose. Its FKM construction is reinforced with Aramid fibre.
Not recommended for use with straight methanol.

This hose has a maximum working pressure of 0.69 MPa (100 psi or 6.9 bar) and is suitable for use in normal operating temperatures of -34°C to 100°C and intermittent use at 125°C

In-Tank Fuel Line Hose meets SAE J30R10 requirements for submersible fuel hose.
