Supersedes part nr. 29002052

For models fitted with 32mm or 36mm Dellorto Carburettors.

The Manifold Rubber Connector is designed to minimise heat transfer to the carburettor as well as providing a cushion between the Carburettor and the alloy manifold. This manifold rubber is the correct length for fitting the Carburettor to the Alloy Manifold without modification. The length of the rubber on the carburettor side is correct and does not leave the 3-4mm gap that some other rubber connectors do. The venturi of the rubber is 34mm which allows only a 1mm oversize when fitted to an unmodified Alloy Manifold

It is suitable for to use with the 36mm carburettor for racing and matching the carburettor venturi to the inlet port.

Important: ensure the mainfold rubber is fitted the correct way round. The end with the two ridges is at the carburettor side, and the single ridge to the engine side.

You may also like to consider the RGS Style Manifold and the Manifold Clamps
